PCB Design & Layout

If you have a schematic or a drawing, but do not have time or tools to complete the design, we can help you. With your schematic, we can take your design to completion in the following steps.

·       Design component footprints

·       Establish PCB outline

·       Setup design rules, e.g. spacing, impedance, etc.

·       Place components

·       Perform manual route traces on critical components, e.g. clocks, power, sensitive analog parts, etc.

·       Perform auto router

·       Run design rule checker

·       Produce Gerber files

We can also take your design to reality with PCB fabrication and PCB assembly services.

Please contact at sale@chinapcba.com if you need urgently quote. We will reply you within 2hours after received your email.
